Z270M Extreme4 ASRock Socket LGA 1151 Intel Z270 Chipset 7th/6th Generation Core i7 / i5 / i3 / Pentium / Celeron Processors Support DDR4 4x DIMM 6x SATA3 6.0Gb/s Micro-ATX Motherboard (Refurbished)
$171.48
- Part No. : Z270M Extreme4
- Product Type: Motherboard
- Brand : ASRock
Specifications:
- Manufacturer : ASRock
- Manufacturer Part # : Z270M Extreme4
- Product Type : System Board
- Form Factor : Micro ATX
- CPU Socket Type : LGA 1151
- Supported CPU(s) : Intel Celeron ProcessorIntel Core i3 ProcessorIntel Core i5 ProcessorIntel Core i7 ProcessorIntel Pentium Processor
- Chipset : Intel Z270
- Number of Memory Slot(s) : 4
- Number of Memory Channel(s) : 2
- Supported Memory Standard(s) : PC4-17000 (DDR4-2133)PC4-19200 (DDR4-2400)PC4-23466 (DDR4-2933)PC4-25600 (DDR4-3200)
- Maximum Installed Memory : 64 GB
- Expansion Slots : PCI-E 3.0 x1PCI-E x16
- Storage Controller : SATA 6.0 Gbps
- Audio Controller : Realtek ALC1220
- Network : Gigabit Ethernet
- Connectors/Ports : 24-pin ATX Power Connector8-pin 12V Power ConnectorChassis Fan ConnectorCOMCPU Fan ConnectorD-SubDVI-DPS/2 KeyboardPS/2 MouseRJ-45
- Connectors/Ports Details : Connector1 x COM Port Header1 x TPM Header1 x Chassis Intrusion Header1 x Power LED and Speaker Header1 x AURA RGB LED Header*1 x CPU Fan Connector (4-pin)1 x CPU Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)1 x Chassis Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)1 x 24 pin ATX Power Connector (Hi-Density Power Connector)1 x 8 pin 12V Power Connector (Hi-Density Power Connector)1 x Front Panel Audio Connector (15μ Gold Audio Connector)1 x Thunderbolt™ AIC Connector (5-pin)1 x Thunderbolt™ AIC Connector (10-pin)2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Intel® Z270) (Supports ESD Protection (ASRock Full Spike Protection))2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection (ASRock Full Spike Protection))1 x Vertical Type A USB 3.1 Gen1 (Intel® Z270)Rear Panel I/O1 x PS/2 Mouse/Keyboard Port1 x D-Sub Port1 x DVI-D Port1 x HDMI Port1 x Optical SPDIF Out Port1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ASMedia ASM2142) (Supports ESD Protection (ASRock Full Spike Protection))1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ASMedia ASM2142) (Supports ESD Protection (ASRock Full Spike Protection))4 x USB 3.1 Gen1 Ports (Intel® Z270) (Supports ESD Protection (ASRock Full Spike Protection))1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
| brand | ASRock |
|---|---|
| Condition | Used |
